Green veneer clipper
Green veneer clipper
A Green Veneer Clipper is used to cut freshly peeled (wet) veneer into required lengths immediately after the peeling process. It ensures precise cutting, smooth edges, and stable operation, improving veneer handling efficiency in plywood production lines.
The machine features automatic length setting, pneumatic or hydraulic cutting system, and synchronized conveyor feeding. Typical parameters include working width 1,300–2,700 mm, cutting thickness 0.8–4.0 mm, cutting speed up to 100 m/min, and servo-controlled positioning for accurate length control.
It is an essential unit in veneer production, helping optimize workflow and reduce material waste before the drying stage.
The machine features automatic length setting, pneumatic or hydraulic cutting system, and synchronized conveyor feeding. Typical parameters include working width 1,300–2,700 mm, cutting thickness 0.8–4.0 mm, cutting speed up to 100 m/min, and servo-controlled positioning for accurate length control.
It is an essential unit in veneer production, helping optimize workflow and reduce material waste before the drying stage.
Quantity:
Green Veneer Clipper
1. Detailed Product Description
AGreen Veneer Clipper is specifically engineered for trimming and sizing green veneer after it exits the peeling machine. It incorporates:
- Automatic feeding system — conveys veneer continuously and straight into the cutting area.
- Precision cutting unit — can be equipped with pneumatic or hydraulic drives for stable, repeatable cuts.
- Servo controlled length measuring — ensures accurate size adjustments and reduced waste.
- Sensor detection — optional sensors quickly detect defects and ensure only qualified portions are processed.
- Robust industrial frame — designed for stable operation, reduced vibration and long service life.
This machine significantly enhances production efficiency and ensures consistent veneer quality for subsequent drying, grading, or assembling operations in panel and plywood plants.
2. Key Features & Advantages
2.1 High Efficiency & Precision
- Automatic feeding and synchronized cutting greatly speeds up the clipping process compared to manual trimming.
- Accurate servo positioning and controlled cut length minimize material waste and production downtime.
2.2 Adaptability & Flexibility
- Suitable for a range of veneer sizes with customizable working widths and cutting thicknesses.
- Works with both pneumatic and hydraulic cutting systems depending on production requirements.
2.3 Improved Material Utilization
- By clipping off defects, uneven edges, and unusable sections, the machine improves quality and increases usable yield from each log. This results in less waste during drying and later processes.
2.4 User‑Friendly Operation
- Simple operator interface with automatic feed adjustments.
- Integrated sensors and detectors improve operational precision and reduce labor costs.
2.5 Durable & Industrial Design
- Heavy‑duty structural components ensure long‑term durability even in continuous production environments.
- Efficient removal of waste pieces helps maintain cleanliness and stability in plant operations.
3. Main Uses & Application Scenarios
TheGreen Veneer Clipper is indispensable in the wood panel and plywood production line. Typical application scenarios include:
3.1 Industrial Veneer Processing
- Cuts veneer immediately after peeling to precise lengths before drying, grading, and further processing.
3.2 Plywood Manufacturing
- Removes defects and trims uneven edges from green veneer to enhance quality and uniformity before stacking and pressing.
3.3 Furniture & Decorative Panel Production
- Produces consistently sized veneer for decorative applications, laminate panels, and hardwood surfaces.
3.4 Wood Composite Panels
- Prepares veneer feedstock for manufacturing particleboard, MDF, HDF and other engineered wood products.
In all these contexts, the Green Veneer Clipper helps reduce labor costs, enhance yield, and streamline the veneer workflow from peeling through finishing.
4. Technical Parameter
| Deacription | Parameters |
| Upper Knife Length | 1350(675x2No.s) |
Down Knife length | 1350 |
| Work Width | ≥150 |
| Work Length | 960-1300 |
| Work Thickness | 1.0-4.0 |
| Quantity of sensor | 10 |
| Feeding Speed | 0-30 |
| Measurement | L:7.15m*W:2.27m*H:1.922m |
| Total Power | 5 |
| Total Weight | 2150 |
