Automatic Plywood Roller DD Saw
Automatic Plywood Roller DD Saw
The automatic plywood roller DD saw is a high-efficiency plywood edge trimming saw machine designed for continuous panel cutting and sizing. This advanced roller type plywood DD saw integrates automatic feeding, precise cutting, and automatic stacking, making it an ideal solution for modern plywood production lines.
With a continuous roller conveying system, this automatic plywood cutting machine significantly improves productivity while ensuring stable and accurate trimming results. It is widely used for processing plywood, MDF, particle board, and other wood-based panels.
With a continuous roller conveying system, this automatic plywood cutting machine significantly improves productivity while ensuring stable and accurate trimming results. It is widely used for processing plywood, MDF, particle board, and other wood-based panels.
Quantity:
Automatic Plywood Roller DD Saw
1. Detailed Product Description
The Automatic Plywood Roller DD Saw integrates automatic feeding, precise cutting, and continuous conveying into one system. The roller-driven feeding mechanism ensures stable panel movement, while the double-disc saw blades perform high-speed trimming on both sides simultaneously.
The machine is designed with a robust steel structure, ensuring durability and long service life even under continuous industrial operation. Its intelligent control system allows operators to easily adjust cutting width and speed, making it suitable for various panel sizes and production requirements.
2. Features and Advantages
2.1 High Precision Cutting
- Double-disc saw (DD Saw) ensures synchronized cutting on both edges
- Smooth and burr-free cutting surface
- High dimensional accuracy for finished plywood panels
2.2 High Efficiency & Automation
- Automatic roller feeding system reduces manual handling
- Continuous operation improves production output
- Suitable for high-volume production lines
2.3 Stable & Durable Structure
- Heavy-duty frame design minimizes vibration
- High-quality components ensure long-term reliability
- Designed for 24/7 industrial use
2.4 Easy Operation
- User-friendly control panel
- Adjustable cutting width and speed
- Low maintenance requirements
2.5 Safety Design
- Equipped with protective covers and emergency stop system
- Ensures operator safety during operation
3. Main Applications & Scenarios
3.1 Plywood Manufacturing Plants
Used for edge trimming and sizing of plywood sheets after pressing.
3.2 Wood Panel Production Lines
Applicable for MDF, particle board, and laminated boards.
3.3 Furniture Manufacturing Industry
Provides accurately sized panels for cabinets, tables, and furniture components.
3.4 Construction Material Processing
Suitable for processing building boards used in construction and decoration.
4. Technical Parameters
| Item | Specification |
|---|---|
| Brand | BM |
| Equipment Includes | Auto feed + Conveyor + Vertical saw + Conveyor + Horizontal saw + Conveyor + Stacker |
| Saw Board Size | 4×8 ft |
| Feeding Conveyor Roller Height | 1015 mm |
| Scoring Saw Size Diameter | φ180 mm |
| Roller Speed of Vertical & Horizontal Cutting Head | 20–70 m/min (Stepless) |
| Speed of Longitudinal Belt Conveyor | 33–110 m/min |
| Thickness Range | 3–40 mm |
| RPM of Saw Blade | 7000 r/min |
| Dust Outlet Holes | 4×108 mm |
| Main Saw Motors | 7.5 kW × 4 |
| Scoring Saw Motor | 1.1 kW × 4 |
| Infeed Table Conveyor Motor | 1.5 kW × 1 |
| Feeding Motor of 4' Cutting Unit + Middle Conveyor | 2.2 kW + 1.5 kW |
| Feeding Motor of 8' Cutting Unit + 8' Auto Pusher + Outfeed Belt Conveyor | 2.2 kW + 0.75 kW + 0.75 kW (Stepless) |
| Total Weight | 12000 Kgs |
| Display Screen | Weinview |
| PLC & Inverter (VFD) | Weichuang (China Brand) |
